Doodads

Doodads

Doodads are reusable, non-interactive map objects — trees, rocks, statues, lamp posts, furniture, props, and any other piece of scenery placed on a map. A doodad defines its visual model or sprite, its collider, the light it emits, and any rotation or translation applied to it, and acts as a template that can be placed any number of times on any number of maps.

Doodads differ from Entities in that they have no scripts, no movement, and no script pages. They exist purely as decorative or environmental objects that the player or other actors can collide with (or pass through), making them the right choice for filling out a scene without the overhead of a fully scripted entity.


Note: Doodads can emit light through the Light property, which is how torches, lanterns, glowing crystals, and other light-source props are typically built — the doodad itself is the visual, and the attached light is what actually illuminates the surrounding scene at runtime.

Properties

System

Name	Explanation	Type
Category	The category of organization for the doodad.	String
Collider	The settings for the dimensions of the doodad collider. Values are measured in tiles.	Collider
Collider Points	The relative X, Y, Z coordinates of the doodad for collision purposes.	Vector
Light	The light that the doodad emits.	Light
Name	The name of the doodad.	String
Rotation	The rotation to apply to the doodad.	Vector
Translation	The translation to apply to the doodad.	Vector

Appearance

Name	Explanation	Type
Shape	The shape of the doodad in 3D.	Sprite Shape
Sprite / Model	The sprite or model of the doodad.	Sprite or Model
Visual	The visual of the doodad in the editor.	Sprite or Model

Collider

Name	Explanation	Type
Ignores Collision	Whether the doodad ignores all collisions.	Toggle
Use Default Collider	Whether the doodad should use the default collider specified in the Map Configuration.	Toggle

Wind

Name	Explanation	Type
Wind Anchor	The anchor point on the sprite for wind sway, in normalized sprite-local coordinates. (0.5, 0) is bottom-center, useful for trees and signs. (0.5, 1) is top-center, useful for hanging banners and lanterns when paired with the Rotate Around Anchor sway mode.	Vector
Wind Eligible	Whether the doodad is influenced by wind.	Toggle
Wind Sway Mode	The mode of sway applied to the doodad when wind is enabled.	Wind Sway Mode
Wind Tolerance	A multiplier on the map's wind strength applied to this doodad's sway.	Number

Wind Sway Mode

Name	Explanation
Along Wind	Top vertices offset opposite to the incoming wind direction, then bob back. Models physical sway — a tree leaning with the wind.
Across Wind	Top vertices wag perpendicular to the wind direction. Reads as a flag flapping or grass shimmering across the breeze.
Rotate Around Anchor	The sprite rotates back and forth around its anchor like a pendulum. Useful for hanging signs, banners, and lanterns.
